Smoke Grenade Launchers NU-40SGLS 37/38-40 MM

Smoke Grenade Launchers NU-40SGLS 37/38-40 MM

Smoke Grenade Launchers NU-40SGLS 37/38-40 MM

PRODUCT CODE: NU40-SGLS

Smoke Grenade Launcher NU-40SGLS 37/38/40 MM is a specially designed non-lethal weapon system for military and anti-riot operations. With its adjustable angle capabilities, it’s a highly flexible tool for managing crowd situations and conducting tactical operations. This system can be easily mounted on military and anti-riot vehicles.

TECHNICAL DOCUMENT
Smoke Grenade Launchers NU-40SGLS 37/38-40 MM – Technical Datasheet
Download the detailed technical documentation including electrical specifications, operating conditions, dimensions, and compliance information.

Smoke Grenade Launchers NU-40SGLS 37/38-40 MM

This smoke discharger is designed to meet the rigorous demands of military and anti-riot operations. It’s a versatile and effective tool for managing crowd situations and conducting tactical operations. The system’s adjustable angle capabilities enable military and anti-riot personnel to quickly and easily modify the trajectory of the smoke grenades for maximum effectiveness.

NU-40SGLS 37/38/40 MM Smoke Grenade Launcher System is a specially designed non-lethal weapon system for military and anti-riot operations. With its adjustable angle capabilities, it’s a highly flexible tool for managing crowd situations and conducting tactical operations. This system can be easily mounted on military and anti-riot vehicles.

Features

  • Adjustable angle capabilities
  • 37/38/40 MM calibers options
  • Robust construction for durability in harsh environments
  • Designed and manufactured according to MIL-STD-81 O and MIL-STD-1275, MIL-STD-461 EMI/EMC military standards
  • Easy-to-use control system
  • Easily customizable
  • Rapid launching capability for quick deployment
  • Cutting-edge control unit

Applications:

  • Anti-riot Vehicles
  • Law enforcement Vehicles
  • Military Vehicles
  • Border patrol vehicles
  • VIP security and protection
Smoke Grenade Launchers

NU-40SGLS 37/38/40 MM Smoke Discharger System is designed to meet the rigorous demands of military and anti-riot operations. It’s a versatile and effective tool for managing crowd situations and conducting tactical operations. The system’s adjustable angle capabilities enable military and anti-riot personnel to quickly and easily modify the trajectory of the smoke grenades for maximum effectiveness.

This non-lethal weapon system can be used in a variety of scenarios such as military tactical operations, anti-riot operations, border patrol operations, and VIP security and protection. The easy-to-use control system simplifies operation, allowing for quick and efficient deployment.

The NU-40SGLS 37/38/40 MM Smoke Grenade Discharger System features a robust construction that’s designed to withstand harsh and rugged environments, ensuring that the system remains operational even in challenging conditions.

Technical Data Table

Shelf Life
10 years
Weight
11 kg ± 0.5 kg
Caliber
37 / 38 / 40 mm
Range
From 30 m to 150 m, depends on selected ammunition
Length
300 mm ± 10 mm
Width
700 mm ± 10 mm
Height
272 mm ± 10 mm
Barrel Length
150 mm
Coating
Zinc–Nickel
Protection Degree
360° – 180° – 120° – 90°
Elevation
15° – 30° – 45°
Power Supply
28 VDC Nominal (16–32)
Power Consumption
6 A ± 2 A @ 28 VDC (Firing Mode)
Activation Type
Resettable Electric Solenoid Activated
